Power Rake Heavy Duty | Blue Diamond

Model

Heavy Duty Power Rake

This Heavy Duty Power Rake from Blue Diamond follows the heels of our previously released Severe Duty model. This lighter unit is perfect for smaller frame skid steers and walk-behind machines. The bolt-on mount lets greater versatility for rental companies and dealers to have the correct model for the suitable machine, with mounts offered for mini and full-size skid steer machines. The working width of the machines in the 10-degree angle is 3″ less than the rotor width, and the 20-degree angle is 6″ less. For example, the 72″ rake has a working width of 69″ in the 10-degree setting and 66″ in the 20-degree setting. This is applicable for all of our rakes, no matter the size family.

Drum widths are between 48”, 60”, and 72” with a 7” diameter drum with 1.5” teeth. Spindles on the drum are 1 3/8” diameter in greaseable bearings, 1.25” spindles with adjustable height.

FEATURES:

  • 7” diameter drum with 1.5” teeth
  • Chain drive unit for increased torque
  • Pre-lubricated chain for easy service
  • Spindles on the drum are 1 3/8” diameter in greaseable bearings
  • Drum widths: 48”, 60” and 72”
  • Overall width 9” more than drum width
  • 7/8” greaseable axles on wheels
  • Airless tires
  • Flip-up wheels
  • 1.25” spindles with adjustable height
  • Bolt-on mount



     Size/Model Working Width  (Straight) Working Width (Angled) Overall Working Width (Straight) Weight
    48" Replaceable Teeth 48" 42" 58" 580lbs
    48" Fixed Teeth 48" 42" 58" 580lbs
    60" Replaceable Teeth 60" 52" 70" 600lbs
    60" Fixed Teeth 60" 52" 70" 600lbs

    72" Replaceable Teeth

    72" 66" 82" 628lbs
    72" Fixed Teeth 72" 66" 82" 628lbs
