Skid Steer Land Grader | Blue Diamond

Land Grader Attachment by Blue Diamond

The Blue Diamond Heavy Duty Land Grader is a high-performance skid steer attachment designed for precise, efficient land leveling and site preparation. Built tough with American steel, this 84-inch land grader delivers fast, accurate grading—perfect for landscaping, construction, driveway maintenance, and more—while saving you time, labor, and material costs.

Key Features & Benefits

• Dual-Direction Grading: Front and rear bolt-on ½-inch thick hardened steel cutting edges let you push or pull material for precise placement and control.
• High-Capacity Boxes: 17 cu. ft. front box + 10 cu. ft. rear box for superior material handling, spreading, and efficiency.
• Independent Blade Articulation: Blade self-articulates up to 8 inches side-to-side (independent of the machine) using ball joints and parallel links—ideal for achieving a smooth, precision-graded surface even on uneven terrain.
• Rear Mounted Wheels: Air-filled tires positioned behind the blade improve mobility, stability, and material flow.
• Durable Construction: 3/16” (7 gauge) steel wrap with rib reinforcements, 3/8” steel side plates, adjustable/replaceable side edges for long-lasting performance in tough conditions.
• Laser-Ready Option: Pair with an optional bolt-on laser receiver kit (laser beacon not included) for automated, ultra-precise laser grading.
• Easy Compatibility: Universal skid steer mount, includes hoses and couplers. Standard flow only (max 25 GPM), minimum 55 HP required. Note: Bobcat models may need a 7-pin adapter.

Specifications

• Operating Width: 84 inches
• Box Height: 19 inches
• Weight: 1,472 lbs
• Front Box Capacity: 17 cubic feet
• Rear Box Capacity: 10 cubic feet
• Hydraulic Flow: Max 25 GPM (standard flow)
• Min. Horsepower: 55 HP
• Material: Heavy-duty certified American steel construction

This heavy-duty land grader excels at transforming rough ground into level perfection—whether you're prepping building sites, smoothing gravel roads, landscaping properties, this attachment is for you.

Upgrade your skid steer or compact track loader with the Blue Diamond Land Grader today for faster, more accurate results and reduced operating costs. Contact us for availability, pricing, or to find a local dealer. Built to last—made in the USA!

Optional laser kit sold separately. Always verify compatibility with your machine.
