Measurements

Grapple Bucket

Root Grapple

Width

44” O.D.

44” O.D.

Hyd. Cylinder

2” Bore by 10” Stroke

2” Bore by 10” Stroke

Grapple Tines

5/16” thick

5/16” thick

Grapple Max Opening

30”

30”

Overall Depth

35 ¾”

35 ½”

Overall Height

27 ¾”

26”

Bucket Height

21”

20”

Bucket Depth

26 3/8”

Does not apply

Pivot Pins

1” DIA: Grease fittings on all pivot points

1” DIA: Grease fittings on all pivot points

Hyd. Hoses

Protective sleeves on all hydraulic lines

Protective sleeves on all hydraulic lines

Hyd. Quick-Disconnects

Flat face couplers included

Flat face couplers included
