Power Rake Extreme Duty | Blue Diamond

Extreme Duty Power Rake

With skid steer machines rising in the industry, there is a need for a more robust and long-lasting soil conditioner attachment. This Premium Power Rake from Blue Diamond is designed to power through jobs where others fail and is set up for simple servicing. The vast 6,000 series motor and optimal drum size produce maximum torque. The engine is kept out of the way, maximizing usable width in tighter areas. Aggressive 2″ teeth are ideal for leaving a fresh seedbed with fewer passes.

This power rake comes with Airless tires – so no flats. Optional bolt-on skid shoes are available to increase the performance of 30% load capacity over side plates alone. It has optional replaceable teeth versus fixed teeth that require welding to replace. Requires 18 – 26 GPM hydraulic flow, max 4000 PSI.

FEATURES

• 6,000 series motor weighs twice what competitive models do and has around 40% more torque.
• 4” x 4″ square tube frame.
• 18 – 26 GPM hydraulic flow, max 4000 PSI
• Optional replaceable teeth versus fixed teeth that require welding to replace.
• 1.5” spindle on castors with spacers versus friction adjusters that work loose.
• Airless tires – no flats.
• 1” front wheel axles versus competitive ¾”.
• 1.5” motor shaft and high-pressure seals.
• 5 position, 20-degree angle, manual or hydraulic.
• Optional bolt-on skid shoes add 30% load capacity over side plates alone.
• 6 3/4” drum diameter, 10 3/4” including teeth.
• Replaceable teeth hardness is HRC 50.
• Double struts on the castors.
