Mounting Frames

Model For
160QT-SS Universal Skid-Steer Mount
160QT-MSS Mini-Skid-Steer Mount
160QT-FL Fits specified telehandler quick-tach
160QT-BH Boom tip attachment for Backhoes and Mini-Excavators
160QT-BLNKB Weld-on attachment plate



Drive Specifications

Attribute 160D-1020 160D-1530 160D-2035 160D-615M 160D-1020M 160D-1530M
Min./Max. Fluid Flow Limits 10-20 GPM 15-30 GPM 20-35 GPM 5-15 GPM 10-20 GPM 15-30 GPM
Max. Intermittent Pressure 3000 PSI 3000 PSI 3000 PSI 3000 PSI 3000 PSI 3000 PSI
Max. Continuous Pressure 3500 PSI 3500 PSI 3500 PSI 3500 PSI 3500 PSI 3500 PSI
Max. Auger Dia. Dirt/Rock 30 in/24 in 36 in/36 in 36 in/36 in 18 in/18 in 30 in/24 in 36 in /36 in



Speed Output
FLOW 160D-1020 160D-1530 160D-2035 160D-615M 160D-1020M 160D-1530M
5 GPM – – – 31 RPM – –
10 GPM 43 RPM – – 61 RPM 53 RPM –
15 GPM 65 RPM 45 RPM – 91 RPM 79 RPM 55 RPM
20 GPM 86 RPM 60 RPM 50 RPM – 105 RPM 73 RPM
25 GPM – 75 RPM 62 RPM – – 92 RPM
30 GPM – 90 RPM 75 RPM – – 110 RPM
35 GPM – – 87 RPM – – –



Torque Output
PRESSURE 160D-1020 160D-1530 160D-2035 160D-615M 160D-1020M 160D-1530M
2000 PSI 1420 ft. lbs. 2041 ft. lbs. 2459 ft. lbs. 1008 ft. lbs. 1165 ft. lbs. 1674 ft. lbs.
2500 PSI 1776 ft. lbs. 2550 ft. lbs. 3075 ft. lbs. 1260 ft. lbs. 1456 ft. lbs. 2092 ft. lbs.
3000 PSI 2131ft. lbs. 3062 ft. lbs. 3688 ft. lbs. 1512 ft. lbs. 1747 ft. lbs. 2511 ft. lbs.
3500 PSI 2486 ft. lbs. 3572 ft. lbs. 4303 ft. lbs. 1764 ft. lbs. 2038 ft. lbs. 2929 ft. lbs.
