Bobcat Skid Steer Models, Sizes, and Operation
Few names are as closely tied to skid steers as Bobcat. Known for their durability, versatility, and wide range of models, Bobcat skid steers are a go‑to for contractors, landscapers, and farmers. Whether you need a compact machine for tight spaces or a larger unit for heavy‑duty work, Bobcat offers options to match nearly every jobsite.
In this article, we’ll take a closer look at the most popular Bobcat skid steer models, their sizes, dimensions, and weight.
Bobcat vs Skid Steer: What’s the Difference?
One of the most common questions people ask is about the difference between a Bobcat and a skid steer. The two terms often get used interchangeably, but they don’t mean the same thing.
A skid steer is a type of compact, engine‑powered machine with lift arms that can be fitted with a wide variety of attachments for digging, hauling, grading, and more. Bobcat, on the other hand, is a brand—one of the most recognized and respected manufacturers of skid steers in the world.
Think of it this way: all Bobcats are skid steers, but not all skid steers are Bobcats. The reason the terms get mixed up is because Bobcat was one of the earliest and most popular brands on the market, and over time the name became synonymous with the machine itself.
In fact, Bobcat has a unique place in history: the company is credited with inventing the first skid steer. In 1957, Cyril and Louis Keller designed an early three-wheeled loader for a local farmer, and by 1960, Bobcat (then Melroe Manufacturing) introduced the M400, the first true skid steer loader. That innovation helped Bobcat become the brand most people associate with these machines today.
So when you see comparisons like “Bobcat vs skid steer” or “skid steer vs Bobcat”, remember that the difference comes down to branding versus machine type. If you’re unfamiliar with skid steers in general, you can start with our comprehensive guide on what a skid steer is, which explains the machine’s design and purpose in detail.
Bobcat Skid Steer Models
Bobcat offers one of the most extensive lineups of skid steers on the market, with models designed to suit everything from small residential jobs to large‑scale construction projects. This wide range is one reason the brand remains a leader in the industry.
- Compact models excel in landscaping and property maintenance, where agility in tight areas is essential.
- Mid‑size models balance power and maneuverability, making them reliable choices for construction, utility work, and farming.
- Heavy‑duty models provide maximum horsepower and lifting capacity, engineered for demolition, land clearing, and large‑scale grading projects.
No matter which category you choose, Bobcat machines are known for their attachment versatility. A single unit can transition from grading to hauling to digging in minutes, making it a valuable investment for contractors and property owners alike. For inspiration on the most useful options, check out our list of the 8 best skid steer attachments.
Bobcat Skid Steer Sizes and Dimensions
When considering a Bobcat, it’s not just about power—it’s also about whether the machine physically fits your jobsite. Skid steer dimensions like width, height, and lift reach determine how easily the machine can access and complete certain tasks. A compact model may be under 60 inches wide and easy to trailer, while larger models can exceed 80 inches in width and require more robust transport.
- Width matters for working in narrow spaces such as gates, sidewalks, or between buildings.
- Height is important when working indoors or in low‑clearance barns, garages, or trailers.
- Lift reach determines how well the skid steer can load materials into trucks, stack pallets, or handle high‑placement tasks.
To make comparisons easier, here’s a Bobcat skid steer size chart that outlines operating weight, width, height, and rated operating capacity (ROC) across popular models:
|
Model |
Width |
Height |
Rated Operating Capacity (ROC) |
|
Bobcat S70 |
35.5 in |
71.4 in |
700 lbs |
|
Bobcat S450 |
58.6 in |
77.8 in |
1,370 lbs |
|
Bobcat S590 |
65.2 in |
77.0 in |
2,000 lbs |
|
Bobcat S66 |
68.0 in |
80.5 in |
2,400 lbs |
|
Bobcat S76 |
74.0 in |
80.5 in |
2,900 lbs |
|
Bobcat S850 |
78.0 in |
83.4 in |
3,950 lbs |
For a deeper look at skid steer specifications, including how size and weight impact performance, take a look at our full guide on how much a skid steer weighs.
How Heavy Is a Bobcat Skid Steer?
Bobcat offers machines ranging from compact loaders weighing under 3,000 pounds to large models that top 10,000 pounds.
Understanding Bobcat skid steer weight is important for transportation, surface protection, and lift capacity.
- Transportation: Heavier models may require larger trailers and tow vehicles.
- Ground impact: Lighter machines are better for sensitive surfaces like lawns.
- Lifting capacity: Generally, the heavier the machine, the more it can lift safely.
| Model | Operating Weight |
|---|---|
| Bobcat S70 | 2,892 lbs |
| Bobcat S450 | 5,019 lbs |
| Bobcat S590 | 6,765 lbs |
| Bobcat S76 | 8,615 lbs |
| Bobcat S850 | 10,237 lbs |
As this chart shows, Bobcat skid steer weight varies widely based on the size and capacity of the machine. Smaller models are easier to transport and maneuver, while heavier machines provide more power for demanding tasks.
How to Operate a Bobcat Skid Steer
Driving a Bobcat skid steer begins with simple steps: After fastening your seatbelt and starting the engine, use the hand or joystick controls to steer and manage the lift arms. Skid steering allows the machine to pivot in tight spaces, but it may take practice to maneuver smoothly.
When carrying loads, always keep the bucket low for stability, and tilt it back slightly to secure the material. Once finished, lower the arms, set the brake, and shut down the engine.
With the right training and a little practice, operating a Bobcat skid steer quickly becomes a safe and straightforward process. If you’d like to dive deeper into controls, driving tips, and attachment use, don’t miss our complete guide on how to operate a skid steer.
Finding the Right Bobcat Skid Steer for Your Needs
Bobcat’s reputation as the original inventor of the skid steer loader shows why the brand remains one of the most trusted names in the industry. Their machines are versatile, durable, and designed to handle everything from construction and landscaping to farming and property maintenance.
From compact models built for tight spaces to large machines designed for heavy-duty work, Bobcat skid steers offer a wide range of options in size, weight, and capabilities.
At Skid Steers Direct, we’re here to help you get the most out of your Bobcat. The right attachment can turn your machine into a digger, grader, snow mover, or demolition tool, all in minutes. Explore our full range of skid steer attachments or contact us to help you match your Bobcat skid steer with the tools that make every job easier.
